Starting with a smart Zigbee system

The basics

What you need:

1. Smart Zigbee lights
2. A bridge
3. A router with WiFi Connection
4. The Innr app or remote

How to connect your Zigbee lights

1. Start up the Innr app on your phone and make sure you’re connected to your WiFi network
2. Use the app to find your bridge
3. Set up your favourite lighting scenes for every occasion.

What is Zigbee?

Innr Lights are Zigbee certified, and we’re proud for it. But what’s Zigbee, and why is Zigbee important?

Zigbee is targeted at radio-frequency (RF) applications which require a low data rate, long battery life, and secure networking. For any system being used in home automation, the main goal is to reduce human effort by operating various appliances remotely.

Why using a bridge to control your smart lights?

The bridge is the heart of your smart lighting system, and all major smart systems use a bridge to let us ‘speak’ to smart products. The Innr bridge lets you connect your smart lights to the Innr system and control them using the free Innr app on your smartphone or tablet. You’ll be able to control up to 100 smart lights! Instead of burdening the WiFi network like WiFi-bulbs, the Zigbee lights create a mesh network, which increases the signal. The more, the merrier!

Zigbee-quality smart lighting without a bridge, is that possible?

If you really don’t want a bridge, but still want to control your lights with the reliable ZigBee protocol, then you can opt for the Innr Remote Control. With this remote you can operate up to 10 lights without the intervention of a Bridge. To install the remote control with your smart lights, follow these steps:

1. Connect the remote control to a smart light bulb by holding it close to a lamp (distance <5 cm) and then simultaneously press and hold the “Program” and “+” buttons; the green LED will blink slowly.
2. The lamp will now respond by flashing once or twice. About 10 seconds later, the lamp will again flash once or twice to indicate that it is successfully coupled with the remote control. You can now control the lamp.
3. Repeat this process with all the lights you want to couple with the remote control. You can couple up to 10 lamps to a single remote control.

Using the RC110 remote control

• Turn all lights on or off with the large button in the top center on the remote control.
• You can dim the light with the ‘+’ and ‘-‘ buttons on the remote control.
• With the slider switch in “scenes” mode, you have 6 different standard dimming settings: 1 = lowest and 6 = highest light level

For the full Installation Manual and User Manual, go to our downloads-page.

Benefits

• Better lighting using only 10% of the energy

Because our smart lighting solutions uses efficient LED technology you’ll save up on a ton of energy. Dimming the LED’s increases your savings even more. Not only does this help with the environment, it also helps save you some money and earn back the cost of installment.

• No expensive LED dimmers required

Yes, all our smart lights can be dimmed. And the best part is: you’ll be able to do this wirelessly. Which means there’s no need for you to install expensive physical (wall)dimmers. Just use the app and you’ll seamlessly dim your lights without flickering or noise.

• Confuse burglars (and neighbours)

Leaving home for a while? Set up our anti-burglary scenes to sporadically turn Innr lights on and off. This will confuse potential burglars and makes it difficult to tell whether you’re home or not.

Learn more

• Control millions of colours from the palm of your hand

Why stick with just on or off and light or dark? Spice it up a little and get our fun colour LEDs. Add a personal touch to every room and create scenes for every occasion.
